Item Sales Info
Part Number: LNGTA
/
Vendor ID Number: 27
/
Custom:
80 Watt - LED HID Replacement; 5000K; Mogul extended base; Type B Ballast Bypass; 120-277 Volt
87
64
Pack Of: 1
Call for Availability
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Specification
Dimensions
Width: 7.48"
Product Overview
80 Watt - LED HID Replacement; 5000K; Mogul extended base; Type B Ballast Bypass; 120-277 Volt
Product Availability
-
Item has been discontinued and is no longer in stock
Technical Details
Details
Category:
Light Bulbs
Subcategory:
LED Bulbs
Finish:
White /vendors/vendorImages white.jpg
Finish Family:
White /vendors/vendorImages white.jpg
Category:
LED
Sub-Category:
HID Replacements
Volts:
120V-277V
Bulb Dimmable:
Non-Dimmable
Bulb Hours:
50000
Bulb Kelvin:
5000K
Bulb Shape:
HB60
Diameter:
7.48
EA Length:
7.48
Harmonized Codes:
8539.52.0091
Length:
10.12
Lumens:
10000L
Shap Carton Width:
7.48
Ship Carton Height:
10.43
Ship Weight:
2.16
Warranty:
5 Year Limited - Hi-Pro
Weight:
1.72
BAA Compliant:
No
Ballast Bypass Direct:
Ballast Bypass
Ballasting Requirements:
Ballast Bypass
Beam Spread:
115
Bulb ANSI Base:
EX39
Bulb Base:
Mogul Extended
Bulb Finish:
Translucent White
Burning Position:
Universal
Candle Power:
3000
Carton Cubic Feet:
0.3377
Cartons Per Unit:
1
CBCP:
3000
CCT Selectable:
No
CEC:
Exempt - Base Not Regulated
CEC Terse:
Lawful for sale in California
CEC Web Text:
Lawful for sale
Color Temprature:
Natural Light
Country Of Origin:
China
CRI:
80+
DLC Approved:
No
Efficacy:
125.00 LPW
Enclosed Fixture Use:
Yes
Enclosure Rating:
Enclosed Rated Lamp
FCC Compliant:
Yes
Feature 1:
MOL: 10.12 inches, MOD: 7.48 inches
Feature 2:
Superior 80 CRI light quality, 10000 lumens, 5000K natural light, with a 115 degree beam spread
Feature 3:
Rated for enclosed fixtures
Feature 4:
Damp location rated
Feature 5:
80 watt LED replaces 250 watt HID
Feature 6:
Translucent white lens with white housing
Feature 7:
5 Year Limited Warranty, based on average use of Hi-Pro
HID Equivalent:
250W
Housing Color:
White
Incandescent Equivalent:
400W
Installation Notes:
Not for use in vapor tight fixtures.
JA8 Compliant:
No
Lamp Ballast Type A/B/C:
Type B
Lamp Filament:
LED
Lens:
Yes
Lens Finish:
Translucent White
Location Rating:
Damp
Long Description:
Satco's S13113 80 watt 20000 lumen Hi-Bay LED HID Type B ballast bypass replacement lamp with built in surge protection is perfect for industrial and commercial applications. The translucent white bulb features a mogul extended base and a beam spread o
Material:
Plastic
Minimum Compartment Size:
Length: 13.5 in. Width: 13.5 in. Height: 12 in.
Operating Frequency:
50-60Hz
Operating Temp:
-40C (-40F) to +60C (+140F)
Pack Type:
Box
Power Factor:
0.98/0.92
Quantity In Pack:
1
RoHS Compliant:
Yes
Romance Copy:
Satco's 80 watt 20000 lumen Hi-Bay LED HID Type B ballast bypass replacement lamp with built in surge protection is perfect for industrial and commercial applications. The translucent white bulb features a mogul extended base and a beam spread of 115 d
SDS class:
LED_Lamp
Short Description:
80W/LED/HID-HB/5K/120-277V
Style:
Contemporary
Surge Protection:
Built-in surge protection - 6KV
Technology:
LED
Title 20 Compliant:
Exempt
Title 24 Compliant:
No
Wattage Selectable:
No
Watts:
80W
